Reply To: NGW-1 possible error

Home Forums NMEA 0183 NGW-1 possible error Reply To: NGW-1 possible error

#59535
Justin Cohen
Moderator

The NGW is designed to be capable of withstanding this, in the scenario that someone mistakes the red and black for power.

Input Voltage Tolerance: -15V to +15V continuous -35V to +35V short term (< 1 second) Input Protection: Current limited and overdrive protection to 40VDC If we can help further, please just raise a ticket here: Actisense Support
