A2K-PMW NMEA 2000® Bulkhead Connector Panel Mounted Wired Connectors
Panel mount wired connectors available from Actisense allow NMEA 2000 installations through watertight bulkheads (or panels) to be achieved.
Waterproof seals ensure the integrity of the NMEA 2000 connection and bulkhead/panel.
The female panel mount wired connector can easily replace any of the existing ‘drop’ glands on the Actisense QNB-1 to create a quick pluggable NMEA 2000 connection option.
The Actisense range of NMEA 2000 connectors and cables has been designed using our specialist interconnect and NMEA knowledge.
To order the Panel Mounted Wire Connectors, please use product codes:
- A2K-PMW-F NMEA 2000 micro, rear panel mount wired connector Female
- A2K-PMW-M NMEA 2000 micro, rear panel mount wired connector Male
Electrical | |
Rated Current | 4A |
Rated Voltage
|
60VDC
|
Mechanical | |
Contacts | Brass, gold plated |
Contact Carrier | Nylon & GF |
Contact Polarisation | Standard M12 -“A”- polarisation |
Mating Thread | M12 |
Housing | Brass, nickel plated |
Mounting Thread | PG9 (see diagram) |
Mounting Nut | Brass, nickel plated – PG9 |
Mounting Hole Dimensions | 15.3 mm (diameter) |
Wires | 18 AWG (stripped and tinned) |
Wire Jacket | PVC |
Weight
|
20g
|
Approvals and Certifications | |
Protection | IP67 (when mated) |
Operating Temperature | -25°C to +90°C |
Connector Specification | Meets IEC61076-2-101 |
NMEA 2000 Approved | |
RoHS Compliant | |
UL Certified (E321413) |
Actisense is dedicated to providing up-to-date software and resources for our products. Here are some useful tools and documentation to help you make the most of your product:
